Ubiquiti airMAX 5.8GHz (M5) 19dBi Sector Antenna



Key Features



  • 4X4 Multi User MIMO Capability

  • Consistent gain from 4.9 to 6.0 GHz .

  • IP 65 ruggedization

  • Designed for the ePMP 3000 Access Point with an integrated mount



Usage



Continuing the tradition of designing and manufacturing industry leading antenna solutions, the ePMP 3000 4X4 sector antenna encompasses all the key diff erentiations of the Cambium Antenna line and adds 4X4 Multi User MIMO Capability. Designed to work in 5 GHz spectrum and 90 degree coverage, the antenna is an integral part of the ePMP 3000 Access Point and allows for Multi User MIMO Operation.

A small, compact design, integrated ePMP radio mount and GPS antenna integration means this antenna is perfect for the Wireless Integrator.

The excellent null fill capabilities of the antenna allow for broad geographical coverage within a sector even near the base of the tower and the edges of the sector mean



Specifications

Network Compatibility
Yes/No
Gain
5GHz Wireless
compatible
17dBi



Electrical Specifications

  • Frequency Range: 4900-5970MHz

  • Input Impedance: 50Ω

  • 3 dB Beamwidth: Azimuth: 70°

  • 3 dB Beamwidth: Elevation: 6°

  • Electrical Downtilt: -2°

  • Polarization: 2x Horizontal & 2x Vertical

  • Port-to-Port Isolation: >20dB

  • Front-to-Back Ratio: 30dB

  • Maximum Input Power: 5W



Mechanical/Environmental Specifications



  • Mounting Connectors: 4 x RP SMA .

  • Mounting Hardware: Included for mounting to mast diameters 5 cm to 10 cm -10° to +5° degee tilt. Hardware included to connect ePMP access point to back of antenna body

  • Antenna Body: 594 mm x 157 mm x 110 mm

  • Weight Antenna Body: 3.7 kg w/ ePMP 3000 Access Point and Mounting Brackets: 6.3 kg

  • Environmental: IP65 Radome

  • Material: UV Protected ABS

  • Operating Temp: -40°C to 60°C



Read More



(C050910D301A)

SKU C050910D301A
Brand Cambium
Shipping Weight 4.0000kg
Shipping Width 0.750m
Shipping Height 0.150m
Shipping Length 0.200m
Shipping Cubic 0.022500000m3
