CGB 100Ah 12V Deep Cycle Solar Battery



Key Features



  • Nominal Capacity: 100AH @25℃

  • Nominal Voltage: 12VAGM valve regulated sealing technology

  • High strength ABS material for container & lid

  • Wide temperature scope of application (-15~45℃)

  • Best temperature of application (20±5℃)

  • No leaking, safe and reliable

  • Standing or lying down for using, convenient to transport and install

  • High sealed reaction efficiency, little loss of water, no need to add distilled water or electrolyte, simple to use and maintain

  • Low self-discharge rate



Important

battery dangerous good

Special Delivery Information: This product is a dangerous good and can only shipped by road courier - we cannot accept a PO Box. for delivery. Please provide an address where someone will be present to sign for the package.



Specifications

Nominal Voltage 12V
Nominal Capacity (C10) 100Ah (10.5V,at 25℃)
Dimension Length 407mm
  Width 173mm
  Height 209.5mm
  Total Height 234.5mm
Weight Approx. 35.65kg
Capacity C10 100Ah (10.5V, at 25℃)
  C5 80Ah (10.5V, at 25℃)
  C3 75Ah (10.5V, at 25℃)
  C1 55Ah (10.2V, at 25℃)
Internal Resistance Approx. 6 mΩ (25℃)
Max Short-duration Discharge Current 2000A(25℃)
Terminal FP-05/RT-20
  • Specification Sheet



(CGB12100)

SKU CGB12100
Brand Aurizon
Shipping Weight 12.0000kg
Shipping Width 0.300m
Shipping Height 0.200m
Shipping Length 0.200m
Shipping Cubic 0.012000000m3
