1W / 5W / 25W Output Power

5W output power (CB). Approved for 25W when using licensed private/commercial frequencies within 450-520MHz*

*ACMA Licensed users only

80+ Channels

80 Channel UHF CB* plus up to 35 Private Channels.**

*80 Channel UHF CB, 61-63 not present, reserved for future use.

**Must be enabled using CS-410PRO software.

Active Noise Cancel Microphone

This feature allows clear communication by reducing the surrounding noise, especially the unwanted low frequency noise received by the microphone.

CB / Commercial Use

The Compact and Rugged construction makes this product ideal for use in
Commercial environments.

Other Features

• Easy to see White backlit LCD display
• Exclusive automatic repeater scan easily finds local repeaters
• Rugged MIL SPEC construction provides shock & vibration resistance
• Silent Stand-by with CTCSS & Selcall
• Front mounted speaker for clear sound

General

			IC-410PRO
Frequency coverage			476.4250 - 477.4125 MHz (CB) 450.0000 - 520.0000 MHz (LMR)
Number of channels			128 Ch
Type of emission			CB   :  8K50F3E (12.5 kHz) LMR:  8K50F3E (12.5 kHz) / 16K0F3E (25 kHz)
Antenna impedance			50 Ω nominal
Operating temperature range			- 30℃ to +60℃
Power supply voltage			13.8 V DC
Current drain (approx.)	Tx	25 W	7.0 A
		5 W	4.0 A
	Rx	Max. audio	1200 mA
		Stand-by	300 mA
Dimensions (projections not included; W×H×D)			150×40×117.5 mm
Weight (approx.)			0.8kg

Transmitter

	IC-410PRO
RF output power	5W / 1W (CB)  25 / 5W / 1W (LMR)
Modulation	Variable reactancne frequency modulation
Maximum permissible deviation	±2.5 kHz (Narrow) ±5.0 kHz (Wide)
Frequency error	±2.50 ppm

Receiver

	IC-410PRO
Sensitivity at 12dB SINAD	0.25 μV typ.
Audio output power	4.0 W typ. at 5 % distortion with 4 Ω load

Applicable U.S. Military Specifications

Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.



Standard	MIL-810 F Method, Proc.
Low Pressure Storage	500.4 I
Low Pressure Operation	500.4 II
High Temperature Storage	501.4 I
High Temperature Operation	501.4 II
Low Temperature Storage	502.4 I
Low Temperature Operation	502.4 II
Temperature Shock	503.4 I
Solar Radiation	505.4 I
Humidity Induced	507.4
Settling Dust	510.4 III
Vibration	514.5 I
Shock Functional	516.5 I
Shock Transit Drop	516.5 IV

Also meets equivalent MIL STD 810 -C, -D and -E.
All stated specifications are subject to change without notice or obligation.

Supplied Accessories

• Microphone HM-211
• Microphone hanger and screw set
• Microphone hanger cable
• DC power cable
• Mounting bracket
