Ubiquiti UISP PRO Outdoor Ethernet Cable - 305m Reel

Key Features

Ultra durable and weatherproof PE jacket
Protect your networks from the most brutal environments with Ubiquiti’s industrial-grade shielded Ethernet cable
Dramatically improves your Ethernet link states, speeds, and overall performance.

Mechanical
Box dimensions	330 x 330 x 340 mm (13 x 13 x 13.4")
Box weight	12 kg (26.5 lb)
Cable length	305 m (1,000 ft)
Cable color	Black
Cable type	CAT5e, shielded
UV resistance	ASTM G 151/154
Ethernet support	Up to 1 Gbps
Conductor wire gauge	24 AWG
Conductor	Solid bare copper
Conductor diameter	0.500 ± 0.005 mm
Insulation type	Solid polyethylene
Insulation thickness	Avg. 0.26 mm Min. 0.25 mm
Insulation diameter	1.04 ± 0.03 mm
Separation (Polyester wrapping)	Thick: 0.025 mm Extent: 20 mm
Anti-crosstalk divider	None
Cable shield (Aluminum foil)	Thick: 0.060 mm Extent: 18 mm
ESD drain wire	0.4 CCS
Rip cord	Yes
Jacket material	Polyethylene
Jacket thickness	Avg. 0.50 mm Min. 0.46 mm
Jacket outer diameter	6.0 ± 0.30 mm
Jacket color	Black
Storage temperature	-30 to 75° C (-22 to 167° F)
Installation temperature	-20 to 60° C (-4 to 140° F)
Ambient operating temperature	-40 to 80° C (-40 to 176° F)
Standards	ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2)
NDAA Compliant	Yes

Special Delivery Information - Due to product weight, please contact us if freight charges appear excessive.

(UISP-Cable-Pro)

Specifications

TOUGHCable PRO Specifications

Level 1 Shielding Protection Cable CAT5eShielded

Ethernet Support Up to 1 Gbps

Conductor Wire Gauge 24 AWG Conductor Solid Bare Copper

Conductor Diameter 0.500 ± 0.005 mm

Insulation Type Solid PE Insulation Thickness Avg. 0.26 mm, Min. 0.25 mm

Insulation Diameter 1.04 ± 0.03 mm

Separation (Polyester Wrapping) Thick: 0.025 mm, Extent: 20 mm

Anti-Crosstalk Divider

None Cable Shield (Aluminum Foil) Thick: 0.060 mm, Extent: 18 mm

ESD Drain Wire 0.4

CCS Rip Cord Yes

Jacket Material PE

Jacket Thickness Avg. 0.50 mm, Min. 0.46 mm

Jacket Outer Diameter 6.0 ± 0.30 mm

Jacket Color Black

Reference Standard ISO/IEC 11801, TIA/EIA568B.2

Installation Temperature -20 to 60° C (-4 to 140° F)

Storage Temperature -30 to 75° C (-22 to 167° F)

Operation Temperature -40 to 80° C (-40 to 176° F)
