Victron Orion TR DC/DC Converter; 6amp 24/48v - Isolated

Remote on-off The remote on-off eliminates the need for a high current switch in the input wiring.

The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual). Adjustable output voltage: can also be used as a battery charger For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel. IP43 protection.

When installed with the screw terminals oriented downwards. Screw terminals No special tools needed for installation. Input fuse On 12V and 24V input models only.

Brand Victron
Dimensions 130 x 186 x 70mm
Efficiency Percent 89%
Galvanic Isolation Yes - 200 VDC between input, output and case
Input Voltage Range V 16-35
Max Continuous Load Current 8:00 AM
Off Load Current mA < 120 mA
Output Noise mV 2 mV rms
Output Voltage V 48.2
Output Voltage V Adj 40-60 V
Output Power W 280 W
Output Current Continuous 6:00 AM
Humidity Non-Condensing Max. 95%
DC Connections Screw Terminals
Max Cable Crosssection 13 mm2 / AWG6
Under Voltage Shutdown 14 V
Under Voltage Restart 15 V

(VN-OR-24-48-6)

SKU VN-OR-24-48-6
