Telco Industrial Class Omnidirectional Antenna

Key Features

• High gain (min 5 dBi) across all cellular bands

• Industrial grade weatherproof fibreglass radome

• Highest practical wideband gain

• Carrier aggregation ready

• Wide spectrum design, suits all current and planned networks (including 700 MHz 4GX).

Additional Information

• This heavy duty multiband omnidirectional antenna sports an extremely wide bandwidth design - operating on two bands 698-960 MHz, 1710-2700 MHz covering 4G cellular bands with high gain and high efficiency

• Being broadcast grade, this antenna is ideal for LTE small cell deployments

• This is the only high gain omnidirectional antenna on the market capable of covering Telstra and Optus new 4GX and 4G+ 700 MHz (Band 28) and 2600 MHz (Band 7) networks, as well as standard 1800 MHz 4G (Band 3).

• For best 4G performance two antennas should be operated to provide MIMO

• MIMO Bracket available separately

• This is an ideal antenna for remote telemetry and mobile/semi-mobile stations

• Unlike some base station antennas, which have lossy coaxial cable, this antenna has an integrated N Female connector located at its base, allowing for direct attachment of low loss feeder/riser cables

• Designed specifically for mast mounting, the antenna's heavy duty aluminium mounting tube can be mounted using the supplied parallel U-bolt clamp.

Usage

• With the different range of frequencies - Telstra and Optus activated 700 and 2600 MHz networks, Vodafone starting a long range 850 MHz 4G network, Optus operating a 2300 MHz TDD network in some areas, and Telstra running 900 and 2100 MHz 4G in others - deploying a 4G antenna can be a nightmare

• Take full advantage of the blistering fast speed your 4G network offers - regardless of frequency, with this high performance carrier-aggregating antenna.

Specifications / Frequency

Network Compatibility	Yes/No	Gain
Telstra 4GX (700 MHz)		5 dBi
Optus 4G+ (700 MHz)		5 dBi
Telstra Next-G™ (850 MHz)		6 dBi
Vodafone 4G+ (850 MHz)* *Please check Vodafone Coverage Map		6 dBi
Telstra/Optus/Voda 4G (1800 MHz)		8.4 dBi
Optus 4G TDD (2300 MHz)		7.8 dBi
802.11 b/g/n/ac WiFi (2400 MHz)		8.4 dBi
Telstra 4GX Band 7 (2600 MHz)		8.0 dBi

Electrical

• Frequency Range: 698-960 MHz / 1710-2700 MHz

• Input Impedance: 50 Ω

• VSWR: <2.0:1

• Polarisation: Vertical Linear

• Vertical Beamwidth: 30° / 20°

• Radiation: Omnidirectional

• Maximum Power: 150 Watts

Mechanical/Environmental

• Construction: Fibreglass Radome, Aluminium Mounting System

• Cable: none

• Connector: 1x N-Type Female White Bronze

• Wind Rating: 210 km/hr t

• Temperature: -40 °C +60 °C

• Weight: 3 kg

• Dimensions: 1500 x 52 mm (L x Ø)

• Mounting: 35-80 mm Ø pole (min 50 mm for 210 km/hr rating)

This antenna has been laboratory tested in a certified 3D Anechoic Chamber. All electrical specification and performance listed has been produced from real-world test data, and not the product of computer simulation.

• This antenna has an integrated N Female connector at its base.

• cCable not supplied.
