Ubiquiti UniFi Switch - 24 Port, 500W



Key Features



  • 24x Gigabit RJ45 ports

  • 2x SFP ports

  • 1x Serial console port (reserved for future use)

  • Non-blocking throughput: 26 Gbps

  • Switching capacity: 52 Gbps

  • Forwarding rate: 38.69 Mpps

  • Maximum power consumption: 500W

  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE

  • Rackmountable.



Usage



  • Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products

  • The UniFi Switch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.





Switching Performance



  • The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.



PoE+ Flexibility



  • This UniFi Switch model is available with 24 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V passive PoE to simplify your infrastructure

  • By default, the UniFi Switch automatically detects 802.3af/at devices so they automatically receive PoE

  • For 24V passive PoE devices, manually enable 24V passive PoE using the UniFi Controller software.



Fiber Connectivity



  • The UniFi Switch provides fiber connectivity options for easy expansion of your networks

  • This UniFi Switch model includes two SFP ports for uplinks of up to 1 Gbps.



Read More





(US-24-500W)

SKU US-24-500W
Brand Ubiquiti
Shipping Weight 7.5000kg
Shipping Width 0.300m
Shipping Height 0.100m
Shipping Length 0.700m
Shipping Cubic 0.021000000m3
