Telco XPOL 2X2 MIMO 4G + 5G Panel Antenna



Key Features



  • Specifically designed for High Frequency 4G & 5G Networks

  • Stainless steel mounting bracket

  • Ideal for Urban LTE Applications

  • Dual-polarised antenna feed with high isolation

  • Industrial grade weatherproof PVC radome

  • Two integrated N Female or 4.3-10 Connectors

  • Carrier aggregation ready



Usage



  • This heavy duty wideband panel antenna sports an extremely wideband design - operating on two bands 1710-2690 MHz, 3400-3800 MHz

  • This is one of the few antennas on the market capable of covering the newly released 5G frequency, as well as offering fallback 4G support for Band 3 (1800MHz), Band 1 (2100MHz), Band 40 (2300MHz) & Band 7 (2600MHz).

  • This incredibly high performance antenna, is highly recommended for most suburban, metro and fringe applications

  • With this high performance carrier-aggregating antenna, you can take full advantage of the blistering speed your 4G & 5G network offers





Specifications / Frequency



Network Compatibility
Yes/No
Gain
All Carriers 4G (1800 MHz)
compatible
8 dBi
All Carriers 4G (2100 MHz)
compatible
8 dBi
Optus (2300 MHz)
compatible
8 dBi
802.11 b/g/n/ac WiFi (2400 MHz)
compatible
8 dBi
Telstra & Optus 4G (2600 MHz)
compatible
8 dBi
5G Networks (3600MHz) compatible 8.5 dBi



Electrical Specifications



  • Frequency Range: 1710-2690MHz & 3400-3800MHz

  • Input Impedance: 50Ω

  • VSWR: <2:1

  • Polarisation: ±45° (XPOL)

  • Vertical Beamwidth: 60/55° (± 10°)

  • Horisontal Beamwidth: 6055° (± 10°)

  • Front to Back Ratio: >20 dB

  • Inter-Port Isolation: ≤-150dBc (@43dBm)

  • Radiation: Directional

  • Maximum Power: 50 Watts



Mechanical/Environmental Specifications



  • Construction: PVC Radome, 304

  • Cable: none

  • Input Connector: 2x Integrated: N-Type Female or 4.310 Female

  • Wind Rating: 55m/s

  • Temperature: -40 °C +60 °C

  • Weight: 2.1 kg

  • Dimensions: 200*180*85mm (L x W x H)

  • Mounting: 25-72 mm Ø pole



Read More



(XPOL1710-3800PL)

SKU XPOL1710-3800PL
Brand Telco Antennas
Shipping Weight 5.4000kg
Shipping Width 0.400m
Shipping Height 0.280m
Shipping Length 0.400m
Shipping Cubic 0.044800000m3
