Transtector Outdoor 75V PoE Surge Arrester



Key Features



  • 75V line voltage

  • Durable aluminium construction

  • RJ45 Cat5e connectors

  • 100% frame transmission @ 100Mbps.



Usage



  • Outdoor Ethernet-based radio protection (PtP & PtMP) designed for a single line PoE (Power over Ethernet) in an indoor/outdoor enclosure

  • The Transtector ALPU PoE series broadband communications protectors are designed to protect data networks with combinations of high speed data protocols

  • The protection circuits utilize silicon avalance diode technology

  • The unit is of high quality cast aluminium construction providing exceptional durability

  • The unit is outdoor-rated NEMA 3R type and sports flanges for easy mounting

  • The ALPU-POE series feature RJ-45 protection circuits for the Ethernet data pairs pins 1,2 and 3,6 and DC unpolarised power pins 4,5 and 7,8 for any combination of circuits up to 90VDC MCOV

  • The unit is intended to be wall mounted but an optional bracket is available on request to permit a wide range of pole mount applications

  • Design incorporates a dedicated ground stud that must be bonded to the nearest grounding system or master ground rod for proper function

  • The enclosure includes a built-in cable retention feature for improved cable management

  • The metal enclosure has screw down clamps for maximum cable retention. In the unlikely event of surge protection self-sacrifice, the (replaceable) individual protection cards will fail short to disrupt communication.



Specifications / Frequency



Electrical Specifications



  • Data Rate: 100Mbps

  • Input Impedance: 85-115Ω

  • Insertion Loss: <1dB @ 16MHz

  • Sparkover Voltage: <90VDC

  • Voltage protection level @ 100A (10/1000us): <150Vpeak

  • Standards: IEEE 802.11af, GR-1089, NEC 800.100, CE, RoHS compliant



Mechanical/Environmental Specifications



  • Construction: Cast Aluminium

  • Durability: >500 cycles

  • Connector: RJ45 Cat5e

  • Temperature: -40 to +80ºC / 99% non-condensing

  • Environmental Protection Level: NEMA 3R

  • Weight: 400g

  • Dimensions: 182 x 77 x 42mm (L x W x H)



Read More





(ALPU-90M)

SKU ALPU-90M
Shipping Weight 0.0450kg
Shipping Width 0.160m
Shipping Height 0.050m
Shipping Length 0.180m
Shipping Cubic 0.001440000m3
